HDPE Geomembrane is made by high density polyethylene,also named as seepage-proofing membrane/HDPE sheet) is a kind of waterproofing obstructing material.
Classified by smoothness of the surface, it can be divided into smooth geomembrane with double flat and smooth layers and textured geomembrane with one or two textured surface;
Classified by raw material, it can be divided into HDPE geomembrane, LDPE geomembrane, EVA geomembrane.
| Quantity: | |
|---|---|
As liners for potable water
As liners for reserve water (e.g., safe shutdown of nuclear facilities)
As liners for waste liquids (e.g., sewage sludge)
Liners for radioactive or hazardous waste liquid
As liners for secondary containment of underground storage tanks
As liners for solar ponds
As liners for brine solutions
As liners for the agriculture industry
As liners for the aquiculture industry, such as fish/shrimp pond
As liners for golf course water holes and sand bunkers
As liners for all types of decorative and architectural ponds
As liners for water conveyance canals
As liners for various waste conveyance canals
As liners for primary, secondary, and/or tertiary solid-waste landfills and waste piles
As liners for heap leach pads
As covers (caps) for solid-waste landfills
As covers for aerobic and anaerobic manure digesters in the agriculture industry
As covers for power plant coal ash
As liners for vertical walls: single or double with leak detection
As cutoffs within zoned earth dams for seepage control
As linings for emergency spillways
As waterproofing liners within tunnels and pipelines
As waterproof facing of earth and rockfill dams
As waterproof facing for roller compacted concrete dams
As waterproof facing for masonry and concrete dams
Within cofferdams for seepage control
As floating reservoirs for seepage control
As floating reservoir covers for preventing pollution
To contain and transport liquids in trucks
To contain and transport potable water and other liquids in the ocean
As a barrier to odors from landfills
As a barrier to vapors (radon, hydrocarbons, etc.) beneath buildings
To control expansive soils
To control frost-susceptible soils
To shield sinkhole-susceptible areas from flowing water
To prevent infiltration of water in sensitive areas
To form barrier tubes as dams
To face structural supports as temporary cofferdams
To conduct water flow into preferred paths
Beneath highways to prevent pollution from deicing salts
Beneath and adjacent to highways to capture hazardous liquid spills
As containment structures for temporary surcharges
To aid in establishing uniformity of subsurface compressibility and subsidence
Beneath asphalt overlays as a waterproofing layer
To contain seepage losses in existing above-ground tanks
As flexible forms where loss of material cannot be allowed.
GRI-GM13
| NO. | Properties | Test Value | ||||||
| 1 | Company name | Shandong Lianxiang Engineering Materials Co.,Ltd. | ||||||
| 2 | Thickness, mm • lowest individual of 10 values - % | 0.75mm | 1.0mm | 1.25mm | 1.5mm | 2.0mm | 2.5mm | 3.0mm |
| 3 | Density, g/cm3 | 0.94 | ||||||
| 4 | Yield strength, N/mm | 11 | 15 | 18 | 22 | 29 | 37 | 44 |
| 5 | Break strength, N/mm | 20 | 27 | 33 | 40 | 53 | 67 | 80 |
| 6 | Break elongation, % | 700 | ||||||
| 7 | Yield elongation, % | 12 | ||||||
| 8 | Tear resistance, N | 93 | 125 | 156 | 187 | 249 | 311 | 374 |
| 9 | Puncture resistance, N | 240 | 320 | 400 | 480 | 640 | 800 | 960 |
| 10 | Stress crack resistance, hr | ≥500 | ||||||
| 11 | Carbon black content, % | 2.0-3.0 | ||||||
| 12 | Carbon black dispersion, Category | 9 in Categories 1 or 2 and 1 in Category 3 | ||||||
| 13 | Oxidative Induction Time (OIT) (min. ave.) (5) (a) Standard OIT - min. - or - (b) High Pressure OIT - min | 100 400 | ||||||
| 14 | Oven Aging at 85°C (a) Standard OIT (min. ave.) - % retained after 90 days - or - (b) High Pressure OIT (min. ave.) - % retained after 90 days | 55 80 | ||||||
| 15 | UV Resistance (7) (a) Standard OIT (min. ave.) - or - (b) High Pressure OIT (min. ave.) - % retained after 1600 hrs (9) | N.R. (8) 50 | ||||||
and tanks
