Our nonwoven geotextiles are mechanically bonded continuous filament nonwovens made from 100% UV stabilized polypropylene. They have been used for decades as separation, protection and filtration elements in a large number of applications, adding years to the life of any roadway, railroad, landfill or civil / environmental engineering project. They are robust and long lasting. The manufacturing method (a continuous process with endless filaments) guarantees the use of high-quality raw materials.
TenCate nonwovens are resistant to all chemical and biological media usually occuring in soils and construction materials. It cannot be dissolved by water and therefore is harmless to ground water. They are equipped with a UV-stabilizer, providing extended resistance to direct sunlight.Our nonwoven geotextiles are mechanically bonded continuous filament nonwovens made from 100% UV stabilized polypropylene. They have been used for decades as separation, protection and filtration elements in a large number of applications, adding years to the life of any roadway, railroad, landfill or civil / environmental engineering project. They are robust and long lasting. The manufacturing method (a continuous process with endless filaments) guarantees the use of high-quality raw materials.
TenCate nonwovens are resistant to all chemical and biological media usually occuring in soils and construction materials. It cannot be dissolved by water and therefore is harmless to ground water. They are equipped with a UV-stabilizer, providing extended resistance to direct sunlight.
| Quantity: | |
|---|---|
100g-1500g
INNO
5602100000
Our nonwoven geotextiles are mechanically bonded continuous filament nonwovens made from 100% UV stabilized polypropylene. They have been used for decades as separation, protection and filtration elements in a large number of applications, adding years to the life of any roadway, railroad, landfill or civil / environmental engineering project. They are robust and long lasting. The manufacturing method (a continuous process with endless filaments) guarantees the use of high-quality raw materials.
TenCate nonwovens are resistant to all chemical and biological media usually occuring in soils and construction materials. It cannot be dissolved by water and therefore is harmless to ground water. They are equipped with a UV-stabilizer, providing extended resistance to direct sunlight.
Benefits of our Nonwoven Geosynthetics:
Wide range to offer a tailormade solution to your requirement
High long term resistance and robustness
An expert team to advice you the appropriate solution
Quick and easy delivery
Uniform product quality
| Specification | Values | ||||||||||
| Weight (g/m2) | 100 | 150 | 200 | 250 | 300 | 350 | 400 | 450 | 500 | 600 | 800 |
| Weight variation (%) | ±4% | ||||||||||
| Thickness (mm) | 1.2 | 1.6 | 1.8 | 2.1 | 2.4 | 2.6 | 2.8 | 2.9 | 3.0 | 3.2 | 3.4 |
| Width (m) | 1 to 6.5m (5.9m for container transportation) | ||||||||||
| Width deviation (%) | ±0.5% | ||||||||||
| Breaking Strength (≥KN/m) | 5 | 8 | 11 | 15 | 20 | 22 | 24 | 26 | 28 | 34 | 50 |
| Elongation at Break (%) | 50% to 90% | ||||||||||
| CBR Bursting Strength (≥KN/m) | 1.0 | 1.7 | 2.5 | 3.0 | 3.5 | 3.9 | 4.3 | 4.8 | 5.3 | 6.2 | 7.0 |
| Sieve Size (mm) | 0.07 to 0.20 | ||||||||||
| Vertical Permeability Coefficient (cm/s) | ≤2*10-1 | ||||||||||
| Tear Strength (≥KN/m) | 0.15 | 0.24 | 0.35 | 0.39 | 0.42 | 0.46 | 0.50 | 0.53 | 0.58 | 0.65 | 0.9 |
